LED high bay luminaire ACANEO HIAL 37000/840/W/DALI, 262 W, 40,000 lm, 88° wide beam, DALI dimmable - Waldmann 113996000-00804839

For very high halls with wide luminaire spacing, the ACANEO HIAL 37000/840/W/DALI is the brightest version of this range in our assortment: approx. 40,000 lm at approx. 262 W with approx. 152 lm/W. The 88° wide-beam optic spreads the light across the area and suits open zones and lower mounting heights. Its DALI ballast allows continuous dimming and integration into a lighting management system.

Benefits

• Continuously dimmable via DALI, for daylight or presence control with a matching sensor
• 88° wide beam optic: uniform lighting of large, open hall areas
• 4000 K neutral white light, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for consistent light throughout the hall
• IP65, protection class I and operation at ambient temperatures from -30 °C to 50 °C, also for unheated halls and cold areas

Applications

• Production halls and assembly areas
• Open storage and logistics areas
• Very high halls up to 30 m ceiling height
• Halls with lighting management or zone control

Installation and accessories

• Fastening available separately: ceiling bracket, 1-point suspension, trapezoidal hanger or wire rope with wire rope holder
• Mains connection via built-in plug RST 20i5, junction box RST 20i5 and safety glass available as accessories
• Sensors with surface-mounting adaptor and Netcomposer control (NCR) from the ACANEO accessories
