LED pendant luminaire IDOO.line ILP 4000/840/D, middle luminaire, 3950 lm, 4000 K, 1402 mm, silver - Waldmann 114154000-00805700

The ILP 4000/840/D middle luminaire extends an IDOO.line light line by 1402 mm and 3950 lm without an additional mains connection: it is coupled mechanically and electrically to the neighbouring module without tools. At 29 W it reaches 136 lm/W. Neutral white 4000 K with CRI ≥ 80 matches what is usually specified for screen and administrative workstations. The silver aluminium profile goes well with metal and glass surfaces in the room.

Benefits

• 3950 lm at 29 W: 136 lm/W luminous efficiency, energy efficiency class C.
• Direct/indirect with approx. 40 % direct share: prism aperture, UGR ≤ 16 and max. 2700 cd/m² luminance (L65) keep glare off screens, the indirect share brightens the ceiling.
• Tool-free coupling: mechanical and electrical connection without tools, no separate mains connection needed.
• DALI and TouchDIM: digitally dimmable ballast (DALI load 1x), dimming range 1-100 %, alternatively via a standard push button.
• Flicker-free with consistent colour: chromaticity tolerance < 3 SDCM, LED life L90B50 50,000 h, suitable as emergency lighting.

Applications

• Rows of desks and team areas in the office
• Screen workstations in the office
• Administration and clerical work
• Laboratories and practice rooms with desk work

Installation and accessories

• Suspended mounting on steel cable 0.3-0.7 m
• Positioned within the line as middle luminaire, supplied via the through-wiring
• Combines with IDOO.line start, middle and end luminaires, up to 18 m on one mains connection
• Control via DALI or a standard push button (TouchDIM)
• Weight without packaging 4.8 kg
