LED pendant luminaire IDOO.line ILP 4000/830/D, start luminaire, 3750 lm, 3000 K, 1408 mm, white - Waldmann 114179000-00805736

Planning a continuous light line above workstations starts with this start luminaire: the ILP 4000/830/D comes with an approx. 2 m mains lead and, thanks to through-wiring, supplies up to 18 m of light line from a single connection. The 1408 mm module delivers 3750 lm at 29 W, which equals 129 lm/W. Warm white 3000 K with CRI ≥ 80 creates a calm lighting mood for meetings, reception and waiting areas. The white aluminium profile blends in below light ceilings.

Benefits

• 3750 lm at 29 W: 129 lm/W luminous efficiency, energy efficiency class C.
• Direct/indirect with approx. 40 % direct share: prism aperture, UGR ≤ 16 and max. 2700 cd/m² luminance (L65) keep glare off screens, the indirect share brightens the ceiling.
• One mains connection for up to 18 m: further modules run on the through-wiring and need no separate supply.
• DALI and TouchDIM: digitally dimmable ballast (DALI load 1x), dimming range 1-100 %, alternatively via a standard push button.
• Flicker-free with consistent colour: chromaticity tolerance < 3 SDCM, LED life L90B50 50,000 h, suitable as emergency lighting.

Applications

• Rows of desks and team areas in the office
• Meeting and conference rooms
• Reception and waiting areas in medical practices
• Break rooms and lounges

Installation and accessories

• Suspended mounting on steel cable 0.3-0.7 m
• Mains connection via approx. 2 m lead with free stranded wires at the start of the line
• Combines with IDOO.line start, middle and end luminaires, up to 18 m on one mains connection
• Control via DALI or a standard push button (TouchDIM)
• Weight without packaging 4.9 kg
