LED machine luminaire ACURIA.perfect APA 2900/850/MS, 22 W, 2800 lm, 740 mm, snap-fit mounting - Waldmann 114313000-00806649

Long work areas, for example in lathes or transfer lines, need light along the entire machining path. The APA 2900 delivers approx. 2800 lm at 22 W from a housing 740 mm long and 70 mm wide. This version is fixed to the machine wall without tools by a snap-fit connection.

Benefits

• Approx. 2800 lm at 22 W, luminous efficiency approx. 127 lm/W: plenty of light with low power draw on the machine's 24 V DC supply
• Snap-fit connection: tool-free mounting via spring clips integrated into the rear
• IP67 protection, colourless anodised aluminium housing and borosilicate glass cover, built from coolant and lubricant-resistant materials according to the manufacturer
• Rotatable M12 connector (A-coded, 5-pin, 360° rotation, 6 x 60° snap-in positions): the cable can be routed away protected from chips
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Lathes and long machining compartments
• Transfer lines
• Inspection lines with visual checks

Installation and accessories

• Snap-fit fastening, no tools required, mounted version
• Mains lead via built-in plug M12-A-5, matching M12 5-pin connection cables in 3 m or 7 m length
• Runs on 24 V DC without integrated operating device: operating device 100-240 V, 50/60 Hz / 24 V DC with 30 W or 100 W, selected by power consumption (here approx. 22 W)
