LED surface-mounted luminaire DOTOO.line DLA 2000/840/D, end luminaire, 1700 lm, white - Waldmann 114356000-00807933

As the end luminaire it closes the light line and plugs into the previous module mechanically and electrically without tools. The DLA 2000/840/D delivers neutral white light at 4000 K with 1700 lm from 16 W, which equals around 106 lm/W. The white aluminium profile blends into light-coloured ceilings. The prism aperture keeps glare at UGR ≤ 19.

Benefits

• Tool-free mechanical and electrical connection closes the line quickly
• DALI ballast, continuously dimmable, alternatively via a standard push button (TouchDIM)
• Prism aperture with UGR ≤ 19 and luminance ≤ 3000 cd/m² at 65°, suitable for screen work
• Flicker-free, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for a uniform light colour across all modules
• Suitable for emergency lighting, LED life L90B50 50,000 h
• 1700 lm at 16 W, around 106 lm/W: low connected load per metre of light line

Applications

• Offices and VDU workstations
• Laboratories and treatment rooms
• Administration and back office
• Corridors and long room axes as a continuous line

Installation and accessories

• Ceiling mounting as a surface-mounted version, aluminium profile with clear PMMA cover
• Closes the line, supplied via the through-wiring from the start luminaire
• Matching DALI accessories: IR-Quattro-HD-DALI presence detector with AP-Box, DALI MCU rotary dimmer, RC 5 DALI remote control
