LED surface-mounted luminaire DOTOO.line DLA 1500/830/D, start luminaire, 1300 lm, white - Waldmann 114363000-00807940

For even direct light at workstations, the DOTOO.line DLA 1500/830/D provides 1300 lm from 13 W at 3000 K (warm white) over 1128 mm. As the start luminaire it carries the mains connection via a connector terminal and feeds the modules plugged in after it, with up to 18 m of light line on one supply. The white aluminium profile blends into light-coloured ceilings.

Benefits

• DALI ballast, continuously dimmable, alternatively via a standard push button (TouchDIM)
• Prism aperture with UGR ≤ 19 and luminance ≤ 3000 cd/m² at 65°, suitable for screen work
• Flicker-free, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for a uniform light colour across all modules
• Suitable for emergency lighting, LED life L90B50 50,000 h
• 1300 lm at 13 W, around 100 lm/W: low connected load per metre of light line
• Mains connection via connector terminal on this luminaire, up to 18 m of line on one supply

Applications

• Meeting and conference rooms
• Reception and waiting areas in medical practices
• Common rooms in care facilities
• Short room axes, alcoves and counters

Installation and accessories

• Ceiling mounting as a surface-mounted version, aluminium profile with clear PMMA cover
• Mains connection via connector terminal on the start luminaire
• Matching DALI accessories: IR-Quattro-HD-DALI presence detector with AP-Box, DALI MCU rotary dimmer, RC 5 DALI remote control
