LED surface-mounted luminaire DOTOO.line DLA 3000/840/D start luminaire, 26 W, 2750 lm, silver

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED surface-mounted luminaire DOTOO.line DLA 3000/840/D start luminaire, 26 W, 2750 lm, silver - Waldmann 114381000-00807958

Name: LED surface-mounted luminaire DOTOO.line DLA 3000/840/D start luminaire, 26 W, 2750 lm, silver - Waldmann 114381000-00807958
Brand: Waldmann
SKU: WAL-114381000-00807958
Price: 951.15 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Start luminaire for the DOTOO.line surface-mounted light line, 2250 mm long, delivering approx. 2750 lm at 26 W in neutral white 4000 K. It carries the mains connection and supplies up to 18 m of light line. Silver aluminium housing, DALI dimmable, for offices, administration and labs.

Net

€951.15

excl. VAT

Item WAL-114381000-00807958

Manufacturer no. 114381000-00807958

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

At 2250 mm, the module spans long room axes above desk clusters with few joints. As the start luminaire it carries the mains connection, and the through-wiring supplies up to 18 m of line. It delivers approx. 2750 lm at 26 W (around 105 lm/W) in neutral white 4000 K.

Benefits

One mains connection for up to 18 m of line saves supply cables and ceiling outlets.
Modules connect mechanically and electrically without tools.
Neutral white 4000 K for focused work, prismatic diffuser with UGR ≤ 19.
Dimmable via DALI or push button, flicker-free, suitable for emergency lighting.
Silver aluminium profile for a visible, technical line.

Applications

Offices and VDU workstations
Administration and open-plan offices
Laboratories and practices
Meeting rooms
Corridors and long room axes

Installation and accessories

Ceiling mounted, 7.3 kg.
Mains connection via connector, add middle and end luminaires.
Accessories: DALI MCU rotary dimmer, presence detector IR-Quattro-HD-DALI with AP-Box, RC 5 DALI remote control.

Technical data

Manufacturer part no.	114381000
Order number	00807958
EAN	4013330078058
Connected load	220-240 V, 50 Hz, 60 Hz
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 26 W
Standby	approx. 0.15 W
Luminous flux	approx. 2750 lm
Luminous efficiency	approx. 105 lm/W
Light type/-color	Cold white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Glare control	Prism aperture
Light source	LED
Life expectancy LED	L90B50, 50,000 h
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 19
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Operation	External
Housing	Sectional aluminium, Silver
Light source cover	Acrylic (PMMA), Clear
Mains lead	Connector, Start luminaire
Design	mounted version
Fastening	Ceiling mounted
Weight without/incl. packaging	7.3 kg / approx. 9.6 kg
Dimensions (dimensional drawing)	L = 2250 mm
Packaging dimensions	2410 mm x approx. 190 mm x 120 mm
Power factor	approx. 0.98
Special features	Flicker-free, Start luminaire with mains connection, DALI Load 1x, Suitable as emergency lighting, Through-wired, up to 18 m on one mains connection, Mechanical and electrical connection of the individual modules without tools, TouchDIM - dimming via standard switch
Weight	9.6 kg
Manufacturer	Waldmann
Manufacturer Nr.	114381000-00807958
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	Silver
Farbe	Silber
Control and dimming	DALI dimmable
Luminous flux (lumen)	2750 lm
Power (W)	26 W
Colour rendering (Ra)	Ra 80
Mounting type	Surface-mounted
Operating voltage	220-240 V
Series	DOTOO.line
Protection class (IP)	IP40
