LED recessed luminaire DOTOO.line DLE 1000/830/D, 1000 lm, 3000 K, 854 mm, DALI

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED recessed luminaire DOTOO.line DLE 1000/830/D, 1000 lm, 3000 K, 854 mm, DALI - Waldmann 114408000-00808226

Name: LED recessed luminaire DOTOO.line DLE 1000/830/D, 1000 lm, 3000 K, 854 mm, DALI - Waldmann 114408000-00808226
Brand: Waldmann
SKU: WAL-114408000-00808226
Price: 402.32 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED recessed luminaire DOTOO.line DLE 1000/830/D with approx. 1000 lm at 10 W, 3000 K and a length of 854 mm. DALI dimmable, flicker-free and suitable for emergency lighting, prismatic cover with UGR ≤ 19. For meeting rooms, reception and practices.

Net

€402.32

excl. VAT

Item WAL-114408000-00808226

Manufacturer no. 114408000-00808226

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A short, warm white light line for the ceiling: the DOTOO.line DLE 1000/830/D measures 854 mm and emits approx. 1000 lm at 10 W with 3000 K. It creates a calm lighting atmosphere in meeting corners, reception areas or practice corridors and can be dimmed via DALI.

Benefits

Warm white 3000 K, CRI ≥ 80, for a homely lighting atmosphere
Prismatic cover, L65 ≤ 3000 cd/m², UGR ≤ 19: even, low-glare light at the workstation
Approx. 100 lm/W, standby ≤ 0.2 W, power factor approx. 0.97
Flicker-free and suitable for emergency lighting
LED life L90B50 50,000 h, colour tolerance < 3 SDCM
Easy maintenance thanks to readily accessible ballasts

Applications

Reception and waiting areas
Medical practices and care areas
Administrative areas with a homely atmosphere
Meeting and conference rooms

Installation and accessories

Recessed ceiling mounting with fastening brackets, mains connection via connection terminal, external switching
Matching: DALI MCU digital rotary dimmer, IR-Quattro-HD-DALI presence detector with surface-mounting adaptor, RC 5 DALI remote control for the presence detector

Technical data

Manufacturer part no.	114408000-00808226
Order no.	00808226
EAN	4013330079802
Connected load	220-240 V, 50 Hz, 60 Hz
Control gear	Adjustable electronic ballast, digital DALI
Power consumption	approx. 10 W
Standby	≤ 0.2 W
Luminous flux	approx. 1000 lm
Luminous efficiency	approx. 100 lm/W
Light colour	Warm white
Colour temperature	approx. 3000 K
Colour rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	86 °
Glare control	Prism aperture
Life expectancy LED	L90B50 50,000 h
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 19
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Operation	External
Housing	Sectional aluminium, White
Light source cover	Acrylic (PMMA), Clear
Mains lead	Connection terminal
Design	Recessed version
Fastening	Fastening bracket
Weight without/incl. packaging	3.1 kg / approx. 3.5 kg
Dimensions (dimensional drawing)	L = 854 mm
Packaging dimensions	990 x 190 x 115 mm
Power factor	approx. 0.97
Special features	Flicker-free, DALI Load 1x, Suitable as emergency lighting, TouchDIM - dimming via standard switch
Weight	3.5 kg
Manufacturer	Waldmann
Manufacturer Nr.	114408000-00808226
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	1000 lm
Power (W)	10 W
Colour rendering (Ra)	Ra 80
Mounting type	Recessed
Operating voltage	220-240 V
Series	DOTOO.line
Protection class (IP)	IP40
