LED pendant luminaire VIVAA.pendant VIP 6000/930/D, 6400 lm, 3000 K, white textile cable - Waldmann 114483000-00812686
LED pendant luminaire VIVAA.pendant VIP 6000/930/D with approx. 6400 lm at 53 W, warm white 3000 K and CRI ≥ 90. Suspended on a white textile cable, with approx. 55 % indirect light and UGR ≤ 16, diameter 450 mm. For patient rooms, small offices and consultation rooms. Waldmann grants a 20-year manufacturer's warranty on this luminaire.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Patient rooms, meeting corners and small offices with low ceilings call for a warm, even light impression. The VIVAA.pendant VIP 6000/930/D produces approx. 6400 lm at 3000 K and hangs on a white textile cable that blends into the ceiling. CRI ≥ 90 and R9 ≥ 50 render skin tones and materials naturally.
Benefits
- White textile cable that recedes against light ceilings, housing in white painted aluminium
- Approx. 55 % indirect light: ceiling and upper walls are brightened, low rooms feel more open
- Direct and indirect light adjustable separately, so the light distribution follows task and time of day
- UGR ≤ 16 and luminance (L65) ≤ 2800 cd/m² thanks to the prism aperture: suitable for screen workstations
- CRI ≥ 90 and R9 ≥ 50 at approx. 120 lm/W: 6400 lm from 53 W with natural colour rendering
- 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)
Applications
- Patient and care rooms
- Small offices with low ceilings
- Meeting corners
- Consultation rooms in practices
Installation and accessories
- Ceiling mounting as a single luminaire, suspended on a white textile cable
- Mains lead approx. 2 m with 5-pin connector, 220-240 V, 50/60 Hz
- External operation via switch or DALI control (DALI load 2x)
- Matching luminaire shades 450 in beige or anthracite, Casambi module for app control
Technical data
| Manufacturer part no. | 114483000-00812686 |
|---|---|
| Order number | 00812686 |
| EAN | 4013330151867 |
| Connected load | 220-240 V, 50 Hz, 60 Hz |
| Work equipment | Power supply unit |
| Power consumption | approx. 53 W |
| Luminous flux | approx. 6400 lm |
| Luminous efficiency | approx. 120 lm/W |
| Light type/-color | Warm white |
| Colour temperature | approx. 3000 K |
| Color rendering index | CRI ≥ 90, R9 ≥ 50 |
| Light distribution | Direct/indirect, approx. 45 % |
| Glare control | Prism aperture |
| Energy efficiency class | C, E |
| At-risk group | RG0/1 |
| Luminance (L65) | ≤ 2800 cd/m² |
| UGR class (4H 8H, EN 12464-1) | ≤ 16 |
| System of protection/Class | I |
| Technology | Two-stage switchable, Continuously dimmable, DALI |
| Operation | External |
| Housing | Aluminium, Painted, White |
| Light source cover | Acrylic (PMMA), satin finish |
| Mains lead | approx. 2 m, Connector, 5 pin, Single Luminaire |
| Fastening | Ceiling mounted |
| Maximum ambient temperature | 25 °C |
| Weight without/incl. packaging | 5.5 kg / approx. 6.6 kg |
| Packaging dimensions | 585 mm x approx. 475 mm x 175 mm |
| Special features | Power cable white / DIN EN 60598-2-25 / Separated, direct and indirect light individually adjustable / DALI Load 2x / Suitable as emergency lighting |
| Manufacturer's warranty | 20 years (Waldmann general warranty terms) |
| Weight | 6.6 kg |
| Manufacturer | Waldmann |
| Manufacturer Nr. | 114483000-00812686 |
| HS-Code | 94051140 |
| GPSR manufacturer information | WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Sales unit | 1 Stück |
| Colour | White |
| Farbe | Weiß |
| Control and dimming | DALI dimmable |
| Luminous flux (lumen) | 6400 lm |
| Power (W) | 53 W |
| Colour rendering (Ra) | Ra 90 |
| Mounting type | Pendant |
| Operating voltage | 220-240 V |
| Series | VIVAA.pendant |
Downloads
Datasheet
User Manual
Catalogue
