LED surface-mounted luminaire OBLO.fit OBA 1000/840/D, 1500 lm, 4000 K, DALI dimmable - Waldmann 114503000-00813347

Corridors, ancillary rooms and small treatment rooms or offices need a slim, efficient ceiling luminaire rather than a large lumen package. The OBLO.fit OBA 1000/840/D delivers approx. 1500 lm from just 11 W, an efficacy of approx. 136 lm/W and the highest in the range. Neutral white light at approx. 4000 K supports focused work in offices, administration and laboratories. Via DALI the luminaire is continuously dimmable and can be integrated into lighting control systems.

Benefits

• Continuously dimmable via DALI, one DALI load per luminaire (DALI load 1x).
• Opal acrylic (PMMA) cover for even surface brightness, direct component approx. 84 %, luminance (L65) ≤ 3500 cd/m².
• Chromaticity tolerance < 3 SDCM and CRI ≥ 80: several luminaires in one room look uniform in colour.
• Housing of white painted sheet steel with integrated power supply unit, only 0.8 kg net.
• Approx. 136 lm/W luminous efficiency: 1500 lm from 11 W keeps energy demand per room low.

Applications

• Corridors and stairwells in office buildings
• Ancillary rooms, kitchenettes and washrooms
• Small treatment and examination rooms

Installation and accessories

• Ceiling mounting as a surface-mounted luminaire, low series construction height of 85 or 95 mm
• Direct mains connection to 220-240 V AC, 50/60 Hz, protection class I
• Connect the DALI control line in addition to the mains lead
• Accessories: decorative ring OBA 370 or OBA 460 in a RAL colour of choice
