LED desk-mounted luminaire LAVIGO DPT 9000/840/D/G2, 8950 lm, dimmable, white

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED desk-mounted luminaire LAVIGO DPT 9000/840/D/G2, 8950 lm, dimmable, white - Waldmann 121837000-00807253

Name: LED desk-mounted luminaire LAVIGO DPT 9000/840/D/G2, 8950 lm, dimmable, white - Waldmann 121837000-00807253
Brand: Waldmann
SKU: WAL-121837000-00807253
Price: 1325.15 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LAVIGO DPT 9000/840/D/G2 desk-mounted luminaire with approx. 8950 lm at 63 W, continuously dimmable via multi-function switch, no sensor. White housing, approx. 20 % direct light, for offices, administration and meetings. Waldmann grants a 20-year manufacturer's warranty on this luminaire.

Net

€1,325.15

excl. VAT

Item WAL-121837000-00807253

Manufacturer no. 121837000-00807253

Question about this item

Datasheet (PDF) 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The LAVIGO DPT 9000/840/D/G2 desk-mounted luminaire sits right on the desktop and is dimmed continuously with the multi-function switch, without any sensor. With approx. 8950 lm at 63 W and 142 lm/W it serves one screen workstation.

Benefits

Approx. 8950 lm at 63 W power consumption, 142 lm/W luminaire efficacy
Direct/indirect with approx. 20 % direct share, direct light evenly spread by edge light and light-guide technology
UGR ≤ 16 and max. luminance ≤ 3000 cd/m² (L65) for low-glare screen work
Continuously dimmable via multi-function switch, direct and indirect light adjustable separately
Adjustable inclination of the tubular section
20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

Single screen workstation
Administration, clerical work and accounting
Laboratory and practice offices
Offices with little floor space

Installation and accessories

Socket for table adaptor (accessory): TK 1A/30 table clamp for 12-30 mm desktops in white or silver, or slot-in pivot pin with 20-28 mm insertion depth
Mains lead approx. 3.7 m with CEE 7/VII plug

Technical data

Manufacturer part no.	121837000-00807253
Order number	00807253
EAN	4013330123864
Connected load	220-240 V, AC, 50 Hz, 60 Hz
Control gear	Electronic ballast
Power consumption	approx. 63 W
Standby	approx. 0.5 W
Luminous flux	approx. 8950 lm
Luminaire efficacy	approx. 142 lm/W
Light colour	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct/indirect, approx. 20 %
Glare control	Prism aperture
Light source	LED
Life expectancy LED	L80B50 60,000 h
Energy efficiency class	C, D
Chromaticity tolerance LED	< 3 SDCM
Photobiological risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 16
System of protection/Class	IP20, class I
Technology	Continuously dimmable
Operation	Multi-function switch
Housing	Steel/plastic, Painted, White
Light source cover	Acrylic (PMMA), satin
Arm	Steel tube, Painted, Tubular section upright, White
Mains lead	approx. 3.7 m, Mains plug, CEE 7/VII
Fastening	Socket for table adaptor (accessory)
Ambient temperature min./max	25 °C / 25 °C
Decorative contrast side parts	Flint grey
Weight without/incl. packaging	9.5 kg net, 11.9 kg packed
Power factor	approx. 0.91
Special features	Direct and indirect light adjustable separately, flicker-free, tube inclination adjustable, Cradle to Cradle Certified, direct light with edge light and light-guide technology, detachable luminaire head
Manufacturer's warranty	20 years (Waldmann general warranty terms)
Weight	11.9 kg
Manufacturer	Waldmann
Manufacturer Nr.	121837000-00807253
HS-Code	94052140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	Dimmable
Luminous flux (lumen)	8950 lm
Power (W)	63 W
Colour rendering (Ra)	Ra 80
Mounting type	Base / stand
Operating voltage	220-240 V
Series	LAVIGO
Protection class (IP)	IP20
