LED floor lamp LAVIGO TWIN-U DPS 30000/840/R/G2A, 30,500 lm, 4000 K, PIR, silver metallic

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED floor lamp LAVIGO TWIN-U DPS 30000/840/R/G2A, 30,500 lm, 4000 K, PIR, silver metallic - Waldmann 121841000-00808535

Name: LED floor lamp LAVIGO TWIN-U DPS 30000/840/R/G2A, 30,500 lm, 4000 K, PIR, silver metallic - Waldmann 121841000-00808535
Brand: Waldmann
SKU: WAL-121841000-00808535
Price: 2328.27 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Twin-head LED floor lamp with C-shaped base, approx. 30,500 lm neutral white 4000 K and integrated PIR sensor. Placed at the side, it lights two facing desks with a partition. Finish in silver metallic. Waldmann grants a 20-year manufacturer's warranty on this luminaire.

Net

€2,328.27

excl. VAT

Item WAL-121841000-00808535

Manufacturer no. 121841000-00808535

Question about this item

Datasheet (PDF) 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Two facing desks with partition wall and shelves can be lit to standard with one LAVIGO TWIN-U placed at the side. The luminaire delivers approx. 30,500 lm of neutral white light at approx. 145 lm/W and adjusts itself to presence and daylight via the PIR sensor.

Benefits

Direct and indirect light adjustable separately, direct ratio approx. 12 %
Asymmetric light distribution, UGR ≤ 16
Edge light and light-guide technology for homogeneous light exit, flicker-free
Retrofittable with TALK module, luminaire head detachable
20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

Double workstations in open-plan offices
Screen workstations in administration

Installation and accessories

Free-standing C-shaped base, mains lead approx. 3 m with CEE 7/VII plug
Wireless module (EnOcean 868 MHz or Bluetooth LE 2.4 GHz) and matching wireless USB stick available as accessories

Technical data

Manufacturer part no.	121841000-00808535
Order no.	00808535
EAN	4013330118761
Connected load	220-240 V, AC, 50 Hz, 60 Hz
Control gear	Electronic ballast
Power consumption	approx. 210 W
Standby	approx. 0.5 W
Luminous flux	approx. 30,500 lm
Luminous efficiency	approx. 145 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct/indirect, approx. 12 %
Glare control	Prism aperture
Light source	LED
Life expectancy LED	L80B50 60,000 h
Energy efficiency class	C, D
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 16
System of protection/Class	IP 20, I
Technology	Presence and daylight sensor control (PIR)
Operation	Multi-function switch, Touch-LED
Housing	Steel/plastic, Painted, Silver metallic
Light source cover	Acrylic (PMMA), Satine
Arm	Steel tube, Painted, Tubular section upright, Silver metallic
Luminaire base	C-shaped, Silver metallic
Mains lead	approx. 3 m, Mains plug, CEE 7/VII
Fastening	Floor standing base
Decorative contrast side parts	Flint grey
Weight (net)	27.6 kg
Power factor	approx. 0.966
Special features	Integrated light and presence sensor PIR, Asymmetric radiation, Separated, direct and indirect light individually adjustable, Retrofittable with TALK module, Flicker-free, Direct light component with edge light and light-guide technology for homogenous light exit, Luminaire head detachable
Manufacturer's warranty	20 years (Waldmann general warranty terms)
Weight	27.6 kg
Manufacturer	Waldmann
Manufacturer Nr.	121841000-00808535
HS-Code	94052140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	Silver
Farbe	Silbermetallic
Luminous flux (lumen)	30500 lm
Power (W)	210 W
Colour rendering (Ra)	Ra 80
Mounting type	Base / stand
Operating voltage	220-240 V
Series	LAVIGO
Protection class (IP)	IP20
