LED floor lamp LAVIGO TWIN-T DPS 30000/840/R/G2A, 30,500 lm, DALI, PIR, silver metallic

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED floor lamp LAVIGO TWIN-T DPS 30000/840/R/G2A, 30,500 lm, DALI, PIR, silver metallic - Waldmann 121842000-00808553

Name: LED floor lamp LAVIGO TWIN-T DPS 30000/840/R/G2A, 30,500 lm, DALI, PIR, silver metallic - Waldmann 121842000-00808553
Brand: Waldmann
SKU: WAL-121842000-00808553
Price: 2319.21 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED floor lamp in silver metallic with flat rectangular base, DALI and PIR sensor, approx. 30,500 lm at 4000 K. Conical prismatic screen with UGR ≤ 16. For centrally lit groups of up to four screen workstations. Waldmann grants a 20-year manufacturer's warranty on this luminaire.

Net

€2,319.21

excl. VAT

Item WAL-121842000-00808553

Manufacturer no. 121842000-00808553

Question about this item

Datasheet (PDF) 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

On this LAVIGO TWIN-T in silver metallic, a conical prismatic screen limits glare to UGR ≤ 16. Positioned centrally, it supplies up to four screen workstations with approx. 30,500 lm of neutral white light, controllable via DALI and PIR sensor.

Benefits

Conical prismatic screen, luminance L65 ≤ 3000 cd/m²
DALI plus presence and daylight control
Approx. 145 lm/W, power factor approx. 0.966
Silver metallic contrast parts, height 2035 mm
20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

Groups of screen workstations
Open-plan offices with building automation

Installation and accessories

Flat rectangular base, CEE 7/VII plug, approx. 27 kg
Wireless module (EnOcean 868 MHz or Bluetooth LE 2.4 GHz) and matching wireless USB stick available as accessories

Technical data

Manufacturer part no.	121842000-00808553
Order no.	00808553
Light source	LED
Control gear	Electronic ballast
Connected load	220-240 V, AC, 50 Hz, 60 Hz
Power consumption	approx. 210 W
Power factor	approx. 0.966
Luminous flux	approx. 30,500 lm
Luminous efficiency	approx. 145 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct/indirect
Direct ratio	approx. 12 %
Chromaticity tolerance LED	< 3 SDCM
Glare control	Conical prismatic screen
Luminance (L65)	≤ 3000 cd/m²
Unified glare rating (4H 8H)	≤ 16
System of protection	IP 20
Class of protection	I
Technology	Presence and daylight sensor control (PIR), DALI
Operation	Multi-function switch, Touch-LED
Housing	Steel/plastic, Painted, Silver metallic
Light source cover	Acrylic (PMMA), Satine
Arm	Steel tube, Painted, Tubular section upright, Silver metallic
Luminaire base	Rectangular flat
Weight (net)	approx. 27 kg
Mains lead	approx. 3 m, Mains plug, CEE 7/VII
Fastening	Floor standing base
Dimensions	2035 mm
Decorative contrast side parts	Metallic silver
Life expectancy LED	L80B50 60,000 h
Special features	Integrated light and presence sensor PIR, Asymmetric radiation, Separated, direct and indirect light individually adjustable, Retrofittable with TALK module, Flicker-free, Direct light component with edge light and light-guide technology for homogenous light exit, Luminaire head detachable
Manufacturer's warranty	20 years (Waldmann general warranty terms)
Weight	27 kg
Manufacturer	Waldmann
Manufacturer Nr.	121842000-00808553
HS-Code	94052140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	Silver
Farbe	Silbermetallic
Control and dimming	DALI dimmable
Luminous flux (lumen)	30500 lm
Power (W)	210 W
Colour rendering (Ra)	Ra 80
Mounting type	Base / stand
Operating voltage	220-240 V
Series	LAVIGO
Protection class (IP)	IP20
