LED recessed luminaire DOTOO.line CVG 2000/840/D/WS/MD/35°, 18 W, 1950 lm, 38°

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED recessed luminaire DOTOO.line CVG 2000/840/D/WS/MD/35°, 18 W, 1950 lm, 38° - Waldmann 338326010-00809176

Name: LED recessed luminaire DOTOO.line CVG 2000/840/D/WS/MD/35°, 18 W, 1950 lm, 38° - Waldmann 338326010-00809176
Brand: Waldmann
SKU: WAL-338326010-00809176
Price: 253.94 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED recessed luminaire from the DOTOO.line range with approx. 1950 lm at 18 W and a 38° beam angle, UGR ≤ 16. DALI dimmable, flicker-free and suitable for emergency lighting. For VDU workstations and meeting rooms.

Net

€253.94

excl. VAT

Item WAL-338326010-00809176

Manufacturer no. 338326010-00809176

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Where screen work tolerates little glare, glare control is what counts: the DOTOO.line CVG 2000/840/D/WS/MD/35° focuses approx. 1950 lm at approx. 18 W into a 38° beam angle and, according to Waldmann, reaches UGR ≤ 16 and a luminance L65 of no more than 1500 cd/m² cd/m². Luminous efficiency is approx. 108 lm/W, and the DALI ballast is easy to reach for maintenance.

Benefits

38° beam angle, UGR ≤ 16 (4H 8H, EN 12464-1) and L65 ≤ 1500 cd/m² cd/m²
Digitally dimmable DALI ballast (DALI load 1x), alternatively TouchDIM via a standard switch
Flicker-free, CRI ≥ 80, chromaticity tolerance < 3 SDCM at 4000 K neutral white
Maintenance-friendly thanks to easily accessible ballasts, suitable as emergency lighting
Photobiological risk group RG0/1, no labelling required

Applications

VDU workstations with high glare-control requirements
Meeting tables and conference rooms
Practices and laboratories with desk areas

Installation and accessories

Recessed version according to the data sheet, IP20, protection class I
Mains supply 220-240 V, 50/60 Hz
Matching accessories: KIRK Sensor, recessed version (DT8, VTL), and adapter for surface mounting

Technical data

Manufacturer item no.	338326010-00809176
Order number	00809176
EAN	4013330112455
Connected load	220-240 V, 50/60 Hz
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 18 W
Luminous flux	approx. 1950 lm
Luminous efficiency	approx. 108 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	38°
Light source	LED
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 1500 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 16
System of protection/Class	IP20, I
Technology	Continuously dimmable
Housing	Sectional aluminium, Painted, White
Light source cover	Without
Weight without/incl. packaging	1.4 kg / approx. 2.3 kg
Packaging dimensions	990 x 190 x 110 mm
Special features	Flicker-free, DALI Load 1x, Suitable as emergency lighting, Maintenance-friendly due to easily accessible ballasts, Integrated version, TouchDIM (dimming via standard switch)
Weight	2.3 kg
Manufacturer	Waldmann
Manufacturer Nr.	338326010-00809176
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	1950 lm
Power (W)	18 W
Colour rendering (Ra)	Ra 80
Mounting type	Pendant
Operating voltage	220-240 V
Series	DOTOO.line
Protection class (IP)	IP20
