LED recessed luminaire DOTOO.line CVG 2700/840/D/WS/MD/75°, 25 W, 2850 lm, 75°

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED recessed luminaire DOTOO.line CVG 2700/840/D/WS/MD/75°, 25 W, 2850 lm, 75° - Waldmann 338327030-00809196

Name: LED recessed luminaire DOTOO.line CVG 2700/840/D/WS/MD/75°, 25 W, 2850 lm, 75° - Waldmann 338327030-00809196
Brand: Waldmann
SKU: WAL-338327030-00809196
Price: 272.21 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED recessed luminaire from the DOTOO.line range with approx. 2850 lm at 25 W and a 75° beam angle, UGR ≤ 25. DALI dimmable, flicker-free and suitable for emergency lighting. For corridors, reception and ancillary rooms.

Net

€272.21

excl. VAT

Item WAL-338327030-00809196

Manufacturer no. 338327030-00809196

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For broad, even lighting of large areas, the DOTOO.line CVG 2700/840/D/WS/MD/75° spreads approx. 2850 lm at approx. 25 W over a 75° beam angle. With UGR ≤ 25 according to Waldmann, it is intended for circulation and ancillary areas rather than VDU workstations. Luminous efficiency is approx. 114 lm/W, and the DALI ballast is easy to reach for maintenance.

Benefits

75° beam angle, UGR ≤ 25 (4H 8H, EN 12464-1) and L65 ≤ 3500 cd/m² cd/m²
Digitally dimmable DALI ballast (DALI load 1x), alternatively TouchDIM via a standard switch
Flicker-free, CRI ≥ 80, chromaticity tolerance < 3 SDCM at 4000 K neutral white
Maintenance-friendly thanks to easily accessible ballasts, suitable as emergency lighting
Photobiological risk group RG0/1, no labelling required

Applications

Corridors and circulation areas
Reception, waiting areas and break rooms
Ancillary rooms in offices and practices

Installation and accessories

Recessed version according to the data sheet, IP20, protection class I
Mains supply 220-240 V, 50/60 Hz
Matching accessories: KIRK Sensor, recessed version (DT8, VTL), and adapter for surface mounting

Technical data

Manufacturer item no.	338327030-00809196
Order number	00809196
EAN	4013330112509
Connected load	220-240 V, 50/60 Hz
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 25 W
Luminous flux	approx. 2850 lm
Luminous efficiency	approx. 114 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	75°
Light source	LED
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3500 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP20, I
Technology	Continuously dimmable
Housing	Sectional aluminium, Painted, White
Weight without/incl. packaging	1.8 kg / approx. 2.8 kg
Special features	Flicker-free, DALI Load 1x, Suitable as emergency lighting, Maintenance-friendly due to easily accessible ballasts, Integrated version, TouchDIM (dimming via standard switch)
Weight	2.8 kg
Manufacturer	Waldmann
Manufacturer Nr.	338327030-00809196
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	2850 lm
Power (W)	25 W
Colour rendering (Ra)	Ra 80
Mounting type	Pendant
Operating voltage	220-240 V
Series	DOTOO.line
Protection class (IP)	IP20
