LED pendant luminaire IDOO.line ILP 840/D/SR/EINZEL/1134MM, 25 W, 3600 lm, single luminaire, silver - Waldmann 338336050-00809347

Waldmann ✓ Original product Brand new Made in Germany

IDOO.line LED pendant luminaire as a 1134 mm single luminaire in silver, approx. 3600 lm at 25 W, with its own mains lead. Direct and indirect light separately adjustable, DALI dimmable, for offices and practices.

Net
€404.52
excl. VAT
Item WAL-338336050-00809347
Manufacturer no. 338336050-00809347
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For a single desk or work island that does not need a continuous light line, this 1134 mm single luminaire hangs directly above the workplace. Its own 2 m mains lead makes it ready to connect, delivering approx. 3600 lm at 25 W. A luminous efficiency of approx. 144 lm/W keeps energy use per workplace low. The silver painted profile adds a technical accent below the ceiling.

Benefits

  • Approx. 3600 lm from only 25 W, equal to approx. 144 lm/W
  • Direct and indirect light individually adjustable, so the work surface and ceiling can be weighted independently
  • DALI ballast (DALI load 1x), alternatively dimmable via a standard push switch (TouchDIM)
  • Flicker-free neutral white light (4000 K, CRI ≥ 80, chromaticity tolerance < 3 SDCM) for comfortable screen work
  • Own mains lead of approx. 2 m with free stranded wires, no further module required
  • Suitable as emergency lighting, housing in painted sectional aluminium, silver, IP40

Applications

  • Screen workstations in single and double offices
  • Team desks in administration
  • Medical practice and care areas
  • Meeting rooms with medium-length tables

Installation and accessories

  • Suspended on steel cable 0.3-0.7 m
  • Mains connection via the approx. 2 m lead with free stranded wires
  • Matching accessories: KIRK ceiling sensor in the recessed version (4000 K, DT8, VTL) and surface-mounting adapter for the ceiling sensor from the light-line system accessories

Technical data

Manufacturer part no.338336050-00809347
Order number00809347
EAN4013330106379
Type designationIDOO.line ILP 840/D/SR/EINZEL/1134MM
Versionsingle luminaire
Length (per type designation)1134 mm
Connected load220-240 V, 50/60 Hz
Work equipmentAdjustable electronic ballast, digital DALI
Power consumptionapprox. 25 W
Luminous fluxapprox. 3600 lm
Luminous efficiencyapprox. 144 lm/W
Light type/colourNeutral white
Colour temperatureapprox. 4000 K
Color rendering indexCRI ≥ 80
Light distributionIndirect
Chromaticity tolerance LED< 3 SDCM
System of protection/ClassIP40, protection class I
HousingSectional aluminium, painted, Silver
Mains leadapprox. 2 m, with free stranded wires
FasteningSteel cable 0.3-0.7 m
Weight without/incl. packaging3.1 kg / approx. 4.3 kg
Special featuresSeparated, direct and indirect light individually adjustable, Flicker-free, DALI Load 1x, Suitable as emergency lighting, Mechanical and electrical connection of the individual modules without tools, TouchDIM - dimming via standard switch
Weight4.3 kg
ManufacturerWaldmann
Manufacturer Nr.338336050-00809347
HS-Code94051140
GPSR manufacturer informationWALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
Sales unit1 Stück
ColourSilver
FarbeSilber
Control and dimmingDALI dimmable
Luminous flux (lumen)3600 lm
Power (W)25 W
Colour rendering (Ra)Ra 80
Mounting typePendant
Operating voltage220-240 V
SeriesIDOO.line
Protection class (IP)IP40
