LED suspended luminaire IDOO.line ILP 840/D/SR/START/1408MM, 16 W, 2400 lm, silver - Waldmann 338337060-00809359

A continuous light line over VDU workstations begins with the IDOO.line ILP 840/D/SR/START/1408MM start luminaire. Over 1408 mm it provides approx. 2400 lm at approx. 16 W (150 lm/W), carries the mains connection with an approx. 2 m lead and feeds up to 18 m of line through its through-wiring. The silver painted aluminium profile makes the line stand out visibly from the ceiling.

Benefits

• Approx. 150 lm/W luminous efficiency: 2400 lm at approx. 16 W power consumption
• Direct and indirect light set separately: work surface and ceiling controlled independently
• DALI ballast (DALI load 1x), alternatively TouchDIM dimming via a standard switch
• Flicker-free, CRI ≥ 80 and chromaticity tolerance < 3 SDCM at 4000 K neutral white: uniform light colour along the line
• Suitable as emergency lighting, IP40
• Through-wired, up to 18 m on one mains connection, modules joined without tools

Applications

• Starting point of light lines over VDU workstations
• Open-plan offices and administration
• Meeting and training rooms
• Long rows of tables in laboratories and clerical work

Installation and accessories

• Suspended on steel cable, suspension length 0.3-0.7 m
• Mains connection via approx. 2 m mains lead with free stranded wires
• Matching accessories: KIRK Sensor, recessed version (DT8, VTL), and adapter for surface mounting
