Circlip Pliers Classic MagicTips® Outer Rings Straight A 4, 300 mm - Wiha 34702

Wiha Classic circlip pliers 34702 represent the largest straight model in the Classic series for external circlips. Model A 4 at 300 mm is dimensioned for rings from 85 to 140 mm and suits work on large machines, drive shafts, and heavy plant engineering.

Benefits

• MagicTips® SafetyHold: latch secures large circlips on the tips
• 300 mm overall length for the leverage required with large ring diameters
• Straight plier form for direct access
• Slim head for access in confined installation points
• Conforms to DIN ISO 5254 for dimensional accuracy

Technical data

• Model: A 4, straight
• Overall length: 300 mm (12")
• External circlip range: 85-140 mm
• Product dimensions: 303 x 178 x 16 mm (L x W x D)
• Standard: DIN ISO 5254

Applications

For large-scale plant construction, gearbox engineering, and heavy machinery where external circlips in the 85-140 mm range need fitting or removal from shafts or axles. Manufactured in Vietnam, HS code 82032000.
