High-Leverage Industrial Electric Combination Pliers DynamicJoint and OptiGrip 225 mm, VDE - Wiha 38856

The power-assisted Industrial electric combination pliers in 225 mm format use a highly favourable lever ratio and Wiha DynamicJoint for optimal force transfer to induction-hardened cutting edges (approx. 64 HRC). The multi-polished C-70 tool steel head and OptiGrip gripping surface provide safe gripping, holding and cutting in one tool.

Benefits

• 40% less cutting effort thanks to optimised lever geometry
• DynamicJoint: optimal force transfer, handles piano wire and hardened spring steel up to 2.5 mm
• OptiGrip with three-point support: secure workpiece control during work
• Induction-hardened cutting edges approx. 64 HRC: handles hard wires and chains
• Individually tested to IEC 60900: safe on live parts up to 1,000 V AC
• Overall length 225 mm, dimensions 277 x 51 x 28 mm

Technical data

• Overall length: 225 mm (9")
• Product dimensions: 277 x 51 x 28 mm
• Cutting force: 19
• Diameter max.: 2.5 mm
• Medium-hard wire: up to 4.4 mm
• Hard wire: up to 3 mm
• Hardened spring steel: up to 2.5 mm
• Material: C 70 tool steel, specially tempered
• VDE certified: Yes
• Standard: IEC 60900, DIN ISO 5746
• Country of origin: Vietnam

Applications

Heavy electrical installation, cable routing and industrial production with demanding cutting requirements; handles hard wires, springs and chains, and approved for voltage work up to 1,000 V AC.

Manufactured to IEC 60900, DIN ISO 5746 (Vietnam, HS 82032000).
