slimBit electric PlusMinus/Phillips SL/PH2 combination VDE bit - Wiha 34588
The Wiha slimBit electric SL/PH2 x 75 mm combines slotted and Phillips PH2 drives in a single VDE and GS tested bit rated to 1,000 V AC. The slimTECHNOLOGY keeps the blade up to 33 % slimmer than conventional electric bits, maintaining access to deeply recessed fasteners while covering two drive types.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Where electrical installations mix slotted and Phillips PH2 screws, the combination slimBit SL/PH2 eliminates the need to switch bits. slimTECHNOLOGY integrates the protective insulation into the blade directly, reducing the outer diameter by up to 33 % compared to conventional electric bits. Every slimBit electric passes individual piece testing to IEC 60900 and is approved for work on live parts up to 1,000 V AC.
Benefits
- Two drives in one bit: slotted and Phillips PH2 (PlusMinus combination)
- Up to 33 % slimmer blade through integrated protective insulation (slimTECHNOLOGY)
- VDE and GS tested, individually inspected to IEC 60900 up to 1,000 V AC
- Max. torque 5.5 Nm, overall length 75 mm
- Compatible with slimVario® bit holder and slimTorque VDE bit holder
Applications
Ideal for mixed-fastener installation work where both slotted and Phillips PH2 screws are used near live components. Use exclusively with the slimVario® or slimTorque VDE bit holder.
Made in Germany. Manufactured acc. to IEC 60900. HS 82079030.
Technical data
| Drive profile | Slotted/Phillips PH2 (SL/PH2) |
|---|---|
| Overall length | 75 mm |
| Shank diameter | 6 mm |
| Max. torque value | 5.5 Nm |
| VDE certified | Yes |
| Tool for electrics | Yes |
| ESD article | No |
| Weight | 0.012 kg |
| Manufacturer | Wiha |
| Manufacturer Nr. | 2831132 |
| EAN | 4010995345884 |
| HS-Code | 82079030 |
| GPSR manufacturer information | Wiha Werkzeuge GmbH Obertalstraße 3-7 DE-78136 Schonach www.wiha.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| Certification | IEC 60900 |
