Crimp tool automatic for wire-end sleeves hex crimping 0.08-16 mm² 210 mm - Wiha 41246
The Wiha automatic crimp tool 41246 processes wire-end sleeves with and without insulating collar (DIN 46228, EN 50027) in the cross-section range of 0.08 to 16 mm², plus twin sleeves up to 10 mm² - the hexagonal crimping prevents small sleeves from snagging. Automatically adjusted pressure and a feeding aid ensure consistent crimps; an integrated lever allows manual cancellation at any time.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Conventional crimping pliers carry the risk of wire-end sleeves snagging or being crimped incorrectly - generating waste and costing time. The Wiha automatic crimp tool with hex crimping eliminates both problems: automatically adjusted pressing force delivers consistent, high-quality crimps, while the integrated feeding aid prevents the plastic cover from being crimped.
Benefits
- Wide crimping range 0.08-16 mm² (empty sleeves) and 2 x 0.25-2 x 10 mm² (twin sleeves) - two tools in one
- Hex crimping: small wire-end sleeves cannot snag
- Automatically adjusted pressing force for consistent, high-quality crimps
- Feeding aid protects the sleeve and prevents crimping of the plastic cover
- Integrated lever for manual cancellation of the crimping process at any time
- Elastic, impact-cushioning plastic handles for fatigue-reduced work
Applications
- Processing wire-end sleeves with and without insulating collar in electrical installation and switchgear assembly
- Use for empty and twin sleeves in switchgear, terminal strips and busbar terminals
Made in Germany. HS code: 82032000.
Technical data
| Overall length | 210 mm |
|---|---|
| Cross-section min.-max. | 0.08-16 mm² (AWG 28-5) |
| Twin sleeves | 2 x 0.25-2 x 10.00 mm² |
| Product dimensions | 330 x 135 x 25 mm (L x W x D) |
| Crimping type | hex |
| Standard | DIN 46228, EN 50027 |
| Weight | 0.545 kg |
| Manufacturer | Wiha |
| Manufacturer Nr. | 41246 |
| EAN | 4010995412463 |
| HS-Code | 82032000 |
| GPSR manufacturer information | Wiha Werkzeuge GmbH Obertalstraße 3-7 DE-78136 Schonach www.wiha.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| Norm | DIN 46228, DIN EN 50027 |
