Desoldering gun pneumatic for MX-500, MX-5000 and MX-5200 - Metcal MX-DS1

When repairing through hole components, clean removal of solder from the barrel decides the outcome. The Metcal MX-DS1 is a pneumatic desoldering gun that draws molten solder away quickly and thoroughly using the vacuum of a venturi nozzle. It operates on the MX-500, MX-5000 and MX-5200 soldering systems.

Benefits

• Pneumatic operation with venturi nozzle for fast and thorough solder removal
• Ergonomic handle for longer desoldering runs
• Compatible with STDC desoldering tips and the MX-W5DS work stand
• Paper filters in the collector of the handle, easier to change and handle than glass tubes
• Wide range of accessories and wear parts for a long service life

Technical data

Applications

Desoldering of through hole components and connectors, repair and rework on multilayer boards, prototype work and service departments with an existing compressed air supply.

Compatibility and scope of delivery

For the MX-500, MX-5000 and MX-5200 soldering systems. Compressed air is required for operation. The gun is supplied without cable and without further accessories. Matching accessories include MX-DCF1 filter set with 15 paper and 6 felt filters, MX-DCF1L paper filter pack of 40, MX-DCF1F felt filter pack of 20, MX-DAR1 pressure reducer and filter with connections, AC-TC-P desoldering tip cleaner pack of 12, AC-CB1-P cleaning brush for the solder collection chamber pack of 25, AC-CB2-P cleaning brush for the desoldering cartridge chamber pack of 6, MX-DVC-1 venturi nozzle, MX-DSL1 seal for the upper chamber, MX-DSL2 sealing ring for the desoldering cartridge of the upper chamber, MX-DSB rotary coupling for the air connection, MX-DLA locking adjustment pack of 10 and MX-DMK1 care set.
