Alsident 50-4737-1-6. ESD extraction arm system DN50 3 joints, 945 mm, black - table mounting
ESD extraction arm system DN50 3 joints, 945 mm, black - table mounting
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Alsident 50 system has tubes with a diameter of 50 mm and is suitable for air volumes of 45 -85 m3/h. As a result, the system is ideally suited for use in industries with smaller detection tasks, such as the electronics industry, laboratories, laser technology or even for specialist rooms in schools. The ESD-compliant extraction arm naturally complies with DIN EN 61340-5-1 and is earthed with 1MΩ resistor.
- Maintenance-free, conductive O-rings
- Integrated throttle valve which is in open position from the air flow to ensure maximum flow through the unit
- Threaded rods, springs and thumbscrews in acid-resistant stainless steel (AISI 316L)
- Protective grille (accessory) to prevent foreign bodies from being sucked in
- Tested for use in ESD areas according to IEC 61340-5-1:2016
- The earthing cable has a 1 MΩ safety resistor
- all components RoHS compliant
Technical data
| item number | WL15479 |
|---|---|
| model | 50-4737-1-6 |
| manufacturer | ALSIDENT |
| manufacturer item number | 50-4737-1-6 |
| order unit | piece |
| colour | black |
| material | Tubes in chromated TCP aluminium, joints in conductive polypropylene |
| product series | Alsident System 50 AS |
| joint colour | black |
| air volume extraction arm | 45-85 m³/h |
| diameter of tube | 50 mm |
| assembling | table mounting |
| range | 945 mm |
| number of joints | 3 |
| device series | WSA-10LR, WSA-20LR, WSA-5LR |
| ESD safe | yes |
| Weight | 1.300000 |
| Manufacturer Nr. | 50-4737-1-6 |
| HS-Code | 84149000 |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Denmark |
| ESD version | ESD (antistatic) |
| Certification | IEC 61340-5-1 |
