ERGO slotted screwdriver 0.8 x 4 mm, 175 mm blade, 3-component handle - Bahco BE-8240
With a 175 mm blade the BE-8240 bridges the distance to slotted screws set deep in assemblies or behind covers. The burnished 0.8 x 4 mm tip bites cleanly and the 3-component handle holds the torque. Tool length 297 mm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A slotted screw 15 cm down is a question of blade length, not of force. The BE-8240 offers 175 mm of blade in a 0.8 x 4 mm size, which puts the tool at 297 mm overall.
Benefits in use
- Blade size 0.8 x 4 mm to ISO 2380 and DIN 5264 for a correct fit in standard slotted screws.
- Blade length 175 mm, tool length 297 mm, reaching deep-set screws without an extension.
- Burnished tip for accurate engagement and less cam-out in the slot.
- 3-component handle from the ERGO process, soft material over a rigid surface, handle diameter 17 mm.
- High-performance steel alloy blade, fully hardened and chrome-plated.
- Flat handle sides prevent rolling, the integrated hanging opening suits a tool board.
Applications
Electronics and equipment assembly, maintenance, switchgear and enclosure building, wherever 4 mm slotted screws have to be driven in deep bores or behind components.
Standards and compliance
Blade dimensions to ISO 2380 and DIN 5264. For this model the manufacturer's property table lists neither ESD capability to IEC 61340-5-1 nor VDE testing to IEC 60900. Work on ESD-sensitive assemblies or on live parts calls for tools certified for that purpose.
Technical data
| Feature | Value |
|---|---|
| Model | BE 8240 |
| Length | 330 mm |
| Width | 87 mm |
| Height | 40 mm |
| Sales unit | 1 Stück |
| Content unit | 1 Stück |
| Battery included | no |
| Handle length | 122 mm |
| VDE | no |
| Screw type | slotted |
| ESD-safe | no |
| Packaging | single item |
| Screwdriver type | standard screwdriver |
| Blade thickness | 0.8 mm |
| Handle width | 17 mm |
| Tool length | 297 mm |
| Handle diameter | 17 mm |
| Blade length | 175 mm |
| Blade width | 4 mm |
| Blade gauge | 0.8 mm |
| Weight | 0.1 kg |
| Manufacturer | Bahco |
| Manufacturer Nr. | BE-8240 |
| GPSR manufacturer information | BAHCO Werkzeuge, Maybachstr. 10, DE-71711 Steinheim, www.bahco-werkzeuge.de |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
1 ERGO slotted screwdriver Bahco BE-8240, individually packed.
Downloads
Accessories
ESD version
Bahco BE-8250. Ergo Screwdriver for slotted screws with 3-component handle, 1 mm × 5.5 mm × 150 mm
