ESD shelf mat Ecostat, black, roll 10000x1220x1.5 mm - Warmbier WL19041

The Warmbier ESD shelf mat Ecostat protects electrostatically sensitive components on shelf surfaces and transport trolley surfaces within an EPA. The dissipative covering drains charges in a controlled way and prevents damage from electrostatic discharge during storage and transport.

Construction and properties

• Two-layer composite covering of wear-resistant synthetic rubber
• Volume dissipative
• Solder and heat resistant as well as abrasion resistant
• Halogen-free and permanently elastic

Technical data

• Material: synthetic rubber, two-layer composite covering
• Dimensions: 10000 x 1220 x 1.5 mm (roll material, 10 m)
• Colour: black
• Typical dissipation resistance: 10^6 to 10^7 ohm
• Model: 1452.659.R

Application

For lining shelf boards, shelving units and transport trolleys in the EPA. The roll material is cut to the required size and grounded via the shelf structure.

Standards and compliance

The covering meets the requirements of DIN EN 61340-5-1 for ESD protection.
