Base box 1000 mm ceiling mounting DN 50/63/75 top connection - Alsident 2-1000-20

In workshops and laboratories with high ceilings the extraction arm has to reach working height without the base tube starting to sway. The Alsident 2-1000-20 is a 1000 mm sheet steel base box for ceiling mounting that carries the arm securely and routes the extraction duct at the same time.

Benefits

• Overall length of 1000 mm bridges the gap between ceiling and the required working height
• Very stable sheet steel construction keeps the extraction arm free of vibration in long-term use
• Top connection routes the duct straight into the ceiling void without a visible bend
• TGIC polyester powder coating on all surfaces, inside as well, for increased durability
• Mounting diameter of 100 mm matches Alsident extraction arms in DN 50, DN 63 and DN 75

Technical data

Applications

Ceiling installation of extraction arms above soldering and rework benches, test areas, laboratory tables and filling stations. Wherever extraction has to come down to the workplace from above rather than from the bench, leaving the table surface clear.

Compatibility and scope of delivery

For Alsident extraction arms of the DN 50, DN 63 and DN 75 series in the ceiling mounting version. Supplied as one base box in white with the connection on top. Extraction arm, hood and ducting are not included and are ordered separately.
