Electronics gripping pliers ESD with half-round jaws angled at 45 degrees, 115 mm - Knipex 35 42 115 ESD

When assembling and reworking electronic modules, components have to be held securely, without scratches and without static discharging through the tool. The 35 42 115 ESD electronics gripping pliers have electrically dissipative handles and jaws angled at 45 degrees, half-round with smoothly ground gripping surfaces, at 115 mm length and 70 g.

Benefits

• Robust, load-optimised construction with a box type precision joint that works without backlash.
• Electrically dissipative handles, the tool meets DIN EN 61 340-5 for ESD protected areas.
• Head carefully rounded, so no sharp edges are left that could damage the material.
• Slim sleeves drawn up towards the head allow fine and comfortable gripping between thumb and index finger, head width only 11.0 mm.
• Smoothly ground gripping surfaces for damage-free gripping, plus a low-friction double spring for smooth and even opening.
• The mirror polish with a fine oil film protects against rust. No chrome flakes come loose that could cause circuit faults.

Technical data

Areas of use

Assembly, testing and repair in electronics production, plus precision mechanics, laboratory work and prototyping. The half-round jaws angled at 45 degrees still grip components securely when the pliers are guided flat above the board.

Standards and conformity

The pliers comply with DIN ISO 9655 and DIN EN 61 340-5 for ESD protected areas. According to the manufacturer they contain no substances of very high concern under REACH. The RoHS directive does not apply to this product.
