ERGO slotted screwdriver 1.6 x 8 mm with hexagon shaft, 175 mm blade - Bahco BE-8260
On tight slotted screws the BE-8260 puts through more torque than a plain hand driver, because shaft and bolster are hexagonal and take a spanner. Blade size 1.6 x 8 mm, blade length 175 mm, tool length 297 mm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Large slotted screws do not always come free from the wrist alone. For that case the BE-8260 provides a hexagon bolster for an open-ended spanner, and works with a 175 mm blade in 1.6 x 8 mm.
Benefits in use
- Hexagon shaft and bolster accept a spanner once hand force on the grip is no longer enough.
- Blade size 1.6 x 8 mm to ISO 2380 and DIN 5264 for a wide bearing surface in the slot.
- Blade length 175 mm at 297 mm tool length for deep-set fasteners.
- 3-component handle with 36 mm handle diameter and 122 mm handle length for high manual torque.
- Burnished tip and a fully hardened, chrome-plated high-performance steel alloy blade.
- Flat handle sides against rolling, integrated hanging opening for the tool board.
Applications
Machine and plant construction, repair and disassembly, wherever tight or corroded slotted screws with an 8 mm slot have to be released.
Standards and compliance
Blade dimensions to ISO 2380 and DIN 5264. For this model the manufacturer's property table lists neither ESD capability to IEC 61340-5-1 nor VDE testing to IEC 60900. Work on ESD-sensitive assemblies or on live parts calls for tools certified for that purpose.
Technical data
| Feature | Value |
|---|---|
| Model | BE 8260 |
| Length | 310 mm |
| Width | 105 mm |
| Height | 35 mm |
| Sales unit | 1 Stück |
| Content unit | 1 Stück |
| Battery included | no |
| Handle length | 122 mm |
| VDE | no |
| Screw type | slotted |
| ESD-safe | no |
| Packaging | single item |
| Screwdriver type | standard screwdriver |
| Blade thickness | 1.6 mm |
| Handle width | 36 mm |
| Tool length | 297 mm |
| Handle diameter | 36 mm |
| Blade length | 175 mm |
| Blade width | 8 mm |
| Blade gauge | 1.6 mm |
| Weight | 0.1 kg |
| Manufacturer | Bahco |
| Manufacturer Nr. | BE-8260 |
| GPSR manufacturer information | BAHCO Werkzeuge, Maybachstr. 10, DE-71711 Steinheim, www.bahco-werkzeuge.de |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
1 ERGO slotted screwdriver Bahco BE-8260, individually packed.
