Alsident 50-4737-3-6. ESD extraction arm system DN50 3 joints, 910 mm, black - wall/ceiling mounting

The Alsident 50 system has tubes with a diameter of 50 mm and is suitable for air volumes of 45 -85 m3/h. As a result, the system is ideally suited for use in industries with smaller detection tasks, such as the electronics industry, laboratories, laser technology or even for specialist rooms in schools. The ESD-compliant extraction arm naturally complies with DIN EN 61340-5-1 and is earthed with 1MΩ resistor.

• Maintenance-free, conductive O-rings
• Integrated throttle valve which is in open position from the air flow to ensure maximum flow through the unit
• Threaded rods, springs and thumbscrews in acid-resistant stainless steel (AISI 316L)
• Acid-resistant POP® rivets for increased durability even when used in aggressive environments
• Protective grille (accessory) to prevent foreign bodies from being sucked in
• Tested for use in ESD areas according to IEC 61340-5-1:2016
• The earthing cable has a 1 MΩ safety resistor
• All components RoHS compliant
