ESD tote box, conductive, black, 400 x 300 x 320 mm, stackable - Warmbier 5310.31

Bulky assemblies and larger lot sizes do not fit into a shallow container. At 320 mm height on a 400 x 300 mm footprint, this tote box offers an internal space of 355 x 255 x 317 mm and is moulded from permanently volume conductive, carbon loaded polypropylene.

Benefits

• 320 mm of depth take tall assemblies and deeply layered small parts.
• Volume conductive polypropylene at 10^4 to 10^5 ohms, the effect lies in the material rather than in a coating.
• Footprint of 400 x 300 mm follows the pallet module, two boxes side by side make up 600 x 400 mm.
• Stackable, so the height of a storage unit can be matched to the shelf pitch.
• Closed handle keeps small parts inside and protects them from being touched.
• Moulded ESD marking makes the suitability for the protected area visible.

Application

The box is used inside the EPA for storing and moving assemblies, housings and small parts, as a picking container on the shelf and as a repacking container at goods-in. Its internal width of 355 x 255 mm matches PCB holders and inserts of the same format.
