Phillips bit PH0, 25 mm long, 1/4 inch drive, pack of 10 - Bahco 59S/PH0

At PH0 a worn bit shows immediately, because the recess is small and the screw usually soft. The short 25 mm body keeps the point of engagement close to the drive, so torque reaches the screw without a detour.

Features

• Size PH0 for small cross-recess screws on devices, connectors and assemblies
• Overall length 25 mm, short load path and good guidance in tight positions
• 1/4 inch hex drive to DIN 3126-C 6.3 and ISO 1173
• High-performance steel alloy, zinc-phosphated for corrosion protection and grip in the recess
• 10 bits per plastic box, so assembly is not interrupted by wear

Technical data

Applications

Electronics and device assembly, service work on small equipment, test and repair benches.

Compatibility and scope of delivery

The 1/4 inch hex shank suits bit holders, ratcheting bit screwdrivers and electric screwdrivers. Supplied as one plastic box with 10 bits.

Standards and notes

The drive conforms to DIN 3126-C 6.3 and ISO 1173. The bits are not VDE insulated and are therefore not approved for live working to IEC 60900. The manufacturer declares no dissipative version to IEC 61340-5-1 for these bits.
