Phillips bit PH3, TiN coated, 50 mm, torsion zone, pack of 5 - Bahco 62TIN/50PH3

The larger the recess, the higher the torque and the harder the blow when the driver shuts off. This PH3 catches it in the torsion zone of the shank, while the titanium nitride layer protects the tip in continuous use.

Features

• Size PH3 in a 50 mm length for large, deep seated cross recess screws
• Torsion zone in the shank that absorbs torque peaks and delays tip failure
• Titanium nitride coating for high wear resistance in series driving
• 1/4 inch hex drive to DIN 3126-C 6.3 and ISO 1173
• Body made from high-performance steel alloy
• 5 bits in a plastic box

Technical data

Applications

Series assembly in machine and vehicle building, production lines, maintenance on large bolted joints.

Compatibility and scope of delivery

Fits bit holders, ratcheting bit screwdrivers and drivers with a 1/4 inch hex socket. The delivery comprises 5 bits in a plastic box.

Standards and notes

The drive conforms to DIN 3126-C 6.3 and ISO 1173. The bits are not VDE insulated and are therefore not approved for live working to IEC 60900. The manufacturer declares no dissipative version to IEC 61340-5-1 for these bits.
