Extraction funnel Easy-Click 60, 230 x 100 mm, for extraction arms - Weller ALFA

At manual soldering stations the shape of the capture opening decides how much solder fume actually reaches the extraction unit. The Weller ALFA extraction funnel widens the capture area to 230 mm across and 100 mm high and can be swapped on the arm without tools thanks to the Easy-Click 60 connection.

Benefits

• Wide 230 mm capture opening for assemblies and several joints within the working area
• 100 mm height allows flat positioning close above the board
• Easy-Click 60 mount for tool-free exchange of capture elements
• Suitable for flexible extraction arms and articulated extraction arms
• Purely mechanical capture element with no electrics, therefore maintenance-free

Technical data

Applications

Capture of solder fume and flux vapour at manual workstations in electronics manufacturing, repair and prototyping. The wide funnel suits work that moves across a larger assembly area rather than staying at one fixed point.

Compatibility and scope of delivery

For flexible and articulated extraction arms with an Easy-Click 60 mount. Adapter Z, not included, is needed to attach the funnel to an aluminium extraction arm without a flexible extraction hose. Delivery comprises one extraction funnel.
