ESD short / long divider for compartments, polypropylene, 353 x 80 x 3 mm, 15 slits - Warmbier 5420.353.20.80

Sorted small part storage in an EPA only works if the dividing walls dissipate as well. This divider is made from permanently volume conductive polypropylene, carries 15 slits at 20 mm spacing and splits Warmbier compartment sets into single cells without charge building up while the grid is rearranged.

Benefits

• Volume conductive polypropylene at a typical 10^4 - 10^5 Ohm, the dissipative property sits in the material and cannot be washed off.
• 15 slits on a 20 mm pitch, the cell size is changed by taking single dividers out.
• Hollow chamber profile, 3 mm material thickness at 550 g/m², stiff and still light.
• High abrasion resistance, even where the grid is rebuilt often.
• One part for two positions: short divider in set 5420.G1.80, long divider in set 5420.G2.80.

Technical data

Application

The divider is used in ESD storage containers that keep printed circuit boards, connectors, semiconductors and small parts apart. It also works as a spare when single dividers in an existing compartment set are broken, and as an addition when a coarse grid has to be subdivided later on.
