Suction arm with LED funnel white 50 mm for WLA 250 - Donaldson Bofa A1020168

On assembly and inspection benches, lamp, magnifier and extraction all compete for the same space above the assembly. Suction arm A1020168 combines light and capture in one part: a white funnel with eight LEDs at its end, connected to the WLA 250 extraction unit with a 50 mm port.

Benefits

• 8 LEDs at the funnel end light the work area without an extra lamp
• White version for bright laboratory and assembly benches
• Arm moves easily to the required angle and holds that position
• Funnel captures fume over a wide area above the work point
• 50 mm connection diameter matched to the WLA-250 device series

Technical data

Applications

Assembly, inspection and test benches, laboratory and prototype work, bonding and dispensing, plus soldering on assemblies without ESD requirements where the work point has to be well lit.

Compatibility and scope of delivery

Intended for the Weidinger WLA 250 extraction unit with 50 mm connection. Scope of delivery: one suction arm with white LED funnel, order unit piece. For ESD protected areas the black version A1020169 is the one to use.
