ESD polycarbonate sheet DPC-300, transparent, dissipative, 2000 x 1000 x 10 mm, 1 sheet/pack - Warmbier 5233.DPC300.10

Machine guards, conveyor covers and protection hoods inside an EPA have to keep the process visible and must not hold a static charge. DPC-300 from Warmbier answers both with transparent polycarbonate of 10 mm thickness and a dissipative surface coating.

Benefits

• Dissipative surface coating with a typical point to point resistance of 10⁵ to 10⁷ ohm, charge drains away in a controlled way instead of sitting on the panel.
• Fully transparent, the process stays visible at the machine, the conveyor and the cleanroom partition.
• High impact resistance of polycarbonate, suitable as a guard panel on running equipment.
• Good machinability and formability, cutting, drilling and bending can be done in house.
• Cleanroom compatible, supplied with a transparent release film that protects the surface in transit and during installation.
• Sheet size 2000 x 1000 mm at 10 mm thickness, 1 sheet per pack.

Technical data

Application

Typical uses are machine covers, conveyor covers, cleanroom partitions and protection hoods, wherever an EPA needs a see through barrier that does not retain charge.

Scope of supply and custom sizes

Supplied as 1 sheet measuring 2000 x 1000 x 10 mm with transparent protective film. Custom cut sizes, special thicknesses, colours and dimensions are available from Warmbier on request.
