Vision EVH001. Lynx EVO Large Field/ Stereo Head
Lynx EVO wide-field stereo head EVH001 for Lynx EVO, Vision Engineering. The stereo head is the heart of the eyepieceless Lynx EVO: a multi-lenticular disc with more than 3.5 million individual lenses spins at high speed and merges the optical paths into a clear, high-contrast image. Without eyepieces, wearers of prescription or safety glasses work directly, the head moves freely and posture stays relaxed. With the 10:1 zoom unit and 0.45x to 2.0x objectives the system reaches 2.7x to 120x, up to 240x with multiplier.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The stereo head is the heart of the eyepieceless Lynx EVO: a multi-lenticular disc with more than 3.5 million individual lenses spins at high speed and merges the optical paths into a clear, high-contrast image. Without eyepieces, wearers of prescription or safety glasses work directly, the head moves freely and posture stays relaxed. With the 10:1 zoom unit and 0.45x to 2.0x objectives the system reaches 2.7x to 120x, up to 240x with multiplier. Original accessories from Vision Engineering are matched to the mechanics and optics of the corresponding microscope series. An existing workstation can thus be extended, or a wear part replaced, without exchanging the instrument. Before ordering, check the match by the manufacturer part number.
Benefits
- The stereo head is the heart of the eyepieceless Lynx EVO: a multi-lenticular disc with more than 3.5 million individual lenses spins at high speed and merges the optical paths into a clear, high-contrast image
- Without eyepieces, wearers of prescription or safety glasses work directly, the head moves freely and posture stays relaxed
- With the 10:1 zoom unit and 0.45x to 2.0x objectives the system reaches 2.7x to 120x, up to 240x with multiplier
- Original part from Vision Engineering
Applications
- Visual inspection and assembly in electronics production
- Laboratory and quality assurance
- Training and workshop
Technical data
| Brand | Vision Engineering |
|---|---|
| Manufacturer part number | EVH001 |
| Product type | Lynx EVO wide-field stereo head |
| Suitable for | Lynx EVO |
| Principle | eyepieceless, multi-lenticular disc |
| System magnification | 2.7x - 240x (depending on configuration) |
| Weight | 6.143 kg |
| Manufacturer | Vision |
| Manufacturer Nr. | EVH001 |
| HS-Code | 90112090 |
| GPSR manufacturer information | VISION Engineering Ltd., Anton-Pendele-Straße 3 DE-82275 Emmering www.visioneng.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | United Kingdom |
