Fine dust extraction for more demanding machining processes, with a brushless high vacuum pump rated 380 m³/h at 96 mbar and a 1.1 kW motor. The wide input range of 90 to 257 volts makes the unit usable worldwide and the cascade of a 6.4 litre bag filter plus a HEPA filter at 99.997 per cent at 0.3 micron allows air to be recirculated. A sound choice wherever several capture points or longer hose runs have to be served.
Fine dust extraction unit DustPro 400, 380 m³/h at 96 mbar, 1.1 kW - Donaldson Bofa 30601043-1608
DONALDSON BOFA Original product
Net price (excl. VAT)
€1,539.55
Item WL34596
Manufacturer no. D0944A
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.D0944A
ConditionNew
Article
WL34596
Frequently Bought Together
- This Item: €1,539.55
- Solder fume extraction unit V1000 iQ 850 m³/h for up to 15 workstations, 230 V - Donaldson Bofa 30811590-1419 €5,662.48
- HEPA and gas combination filter for AD 500 iQ extraction unit - Bofa A1030297 €697.89
Total price
Longer extraction ducting and multiple capture points need more vacuum than a compact unit provides. The DustPro 400 uses a brushless high vacuum pump and reaches 380 m³/h at 96 mbar, so fine dust from milling, engraving, grinding and turning is captured reliably.
Benefits
- Brushless high vacuum pump rated 1.1 kW, 380 m³/h at 96 mbar
- Wide range input of 90 - 257 volts for use at any site
- Polyester bag filter with 6.4 litre capacity, 95 % at 0.9 micron
- Pleated HEPA final filter, 99.997 % at 0.3 micron
- Compact 270 mm x 290 mm footprint despite the higher power class
Technical data
| Item number | WL34596 |
| Model | D0944A |
| Manufacturer | Donaldson Bofa |
| Manufacturer item number | 30601043-1608 |
| Device series | DustPro 400 |
| Dimensions (LxWxH) | 270 mm x 290 mm x 600 mm |
| Air flow | 380 m³/h at 96 mbar |
| Motor rating | 1.1 kW |
| Voltage | 257 V, operating range 90 - 257 V |
| Frequency | 50/60 Hz |
| Nominal current | 12.5 A |
| Noise level | 66 dBA |
| Prefilter | Bag filter 6.4 litres, polyester, 95 % at 0.9 micron |
| Final filter | HEPA, 99.997 % at 0.3 micron, pleated construction |
| Order unit | Piece |
Applications
Fine dust extraction on CNC mills, engraving machines, grinding and turning operations as well as multi-station installations with longer hose runs. Used in prototype shops, dental technology, tool making and electronics production.
Compatibility and scope of delivery
Delivery comprises the DustPro 400 extraction unit with bag filter and HEPA filter. Replacement filters are bag filter A1030241 and HEPA filter A1030287, also used in the DustPro 250.
| Manufacturer Nr. | D0944A |
|---|---|
| Manufacturer | Donaldson Bofa |
| Weight | 0.100000 |
| GPSR manufacturer information | BOFA International Ltd Balena Close 21-22 GB-BH17 7DX Poole www.bofa.co.ul |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
