Desoldering nozzle 21.0 x 13.3 mm for 48-pin TSOP, HCT-900 - Oki H-TS48

On a 48-pin TSOP the fine leads sit closely spaced along two long package sides. If the hot air does not reach them simultaneously, pins bend or neighbouring parts lift with the target. The Oki H-TS48, sized 21.0 mm x 13.3 mm, guides the air onto the package with a matched opening.

Benefits

• Inner size 21.0 mm x 13.3 mm matched to 48-pin TSOP packages
• Enclosing air guidance for even reflow of all leads
• Confined heat input protects neighbouring parts on densely populated boards
• Single nozzle for targeted extension of an existing nozzle set

Technical data

Applications

Removing and placing 48-pin TSOP components such as memory devices in repair, rework, failure analysis and sample building.

Compatibility and scope of delivery

For the Oki HCT-900 hand-held convection tool. Delivery comprises one desoldering nozzle. It is also part of the NZKT-1 nozzle set.
