ESD extraction arm kit 600 mm for WSA-LR fume extractors - ULT WSA-LR-KIT-01
A WSA-LR extraction unit only removes what it actually captures at the joint. This kit supplies the complete capture side: an antistatic Alsident System 50 flex arm with 600 mm reach, a bench holder, 1.5 m of DN50 hose and two hose clamps. The arm is conductive and earthed through a 1 MΩ ground cable, so it suits ESD workplaces to IEC 61340-5-1.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
An extraction unit of the WSA-LR series is only as good as the capture point above the joint. This ULT accessory kit provides that side of the system: a flexible Alsident System 50 flex extraction arm with 600 mm reach, a bench holder, DN50 suction hose and matching clamps.
Benefits
- Flexible arm without a joint, suction nozzle positioned freely at the bench, 600 mm reach
- Antistatic design with 1 MΩ ground cable for use in ESD areas to IEC 61340-5-1
- Complete set of arm, bench holder, 1.5 m DN50 hose and two clamps, no sourcing of single parts
- Suits WSA-5LR, WSA-10LR and WSA-20LR
- All components RoHS compliant
Applications
Retrofitting and extending solder fume extraction at hand soldering and rework benches and in electronics manufacturing. Useful wherever the nozzle has to be repositioned for each assembly while the workplace stays electrostatically protected.
Compatibility and scope of delivery
Intended for the ULT extraction units WSA-5LR, WSA-10LR and WSA-20LR. Scope of delivery: 1 Alsident System 50 flex antistatic extraction arm with flexible hose and suction nozzle, 1 Alsident System 50 bench holder in black, 1 antistatic DN50 suction hose without sleeves, 1.5 m long, 2 DN50 hose clamps.
For use in EPA areas to IEC 61340-5-1, dissipation through the supplied ground cable with 1 MΩ resistance. All components RoHS compliant.
Technical data
| Item number | WL37328 |
|---|---|
| Model | WSA-LR-Kit-01 |
| Manufacturer | ULT |
| Manufacturer item number | WSA-LR-KIT-01 |
| Order unit | set |
| Device series | WSA-5LR, WSA-10LR, WSA-20LR |
| Extraction arm | Alsident System 50 flex, antistatic, bench mounting, without joint |
| Arm reach | 600 mm |
| Suction hose | DN50 antistatic, without sleeves, 1.5 m |
| Hose clamps | 2 pieces DN50 |
| Bench holder | Alsident System 50, black |
| Earthing | ground cable with 1 MΩ resistance |
| ESD safe | yes |
| Weight | 2.500000 |
| Manufacturer Nr. | WSA-LR-KIT-01 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | ESD (antistatic) |
| Nennweite DN [mm] | 50 |
| Certification | IEC 61340-5-1 |
