Micro fine here means a bevel face only 0.7 mm wide ground at 45°, narrow enough to hit single terminations on 0201 and 0402 parts. On a 16 mm tip in the 325 to 358 °C band the heat input stays low enough for delicate boards. It runs in the SHP-T hand piece of the TMT-5000S-1 and TMT-5000S-2 systems.
Soldering tip bevelled 45° 0.7 mm micro fine T series 325-358 °C - Thermaltronics TM60BV007
THERMALTRONICS Original product
Net price (excl. VAT)
€18.61
Item WL38401
Manufacturer no. TM60BV007
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.TM60BV007
ConditionNew
Article
WL38401
Frequently Bought Together
- This Item: €18.61
- Soldering tip bevelled 60° 1.8 mm T series 325-358 °C - Thermaltronics TM60BS602 €13.25
- Soldering tip chisel 30° 0.8 mm micro fine series T - Thermaltronics TM80CH008 €18.61
Total price
Below 0.5 mm pitch every tenth of a millimetre of tip width matters, otherwise heat spreads to the neighbouring lead. This micro fine tip from the T series answers that with a 45° bevel face 0.7 mm wide on a 16 mm tip, working in the low 325-358 °C band.
Benefits
- Micro fine geometry with a 0.7 mm bevel face reaches single pins without touching neighbours
- The 45° grind still puts a usable area on the pad despite the small width
- Slim 16 mm tip leaves the joint visible under a microscope
- Low 325-358 °C band limits heat input into fine pads
- Self regulating on the Curie principle, RoHS compliant
Technical data
| Item number | WL38401 |
| Model | TM60BV007 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM60BV007 |
| Product series | T tip series, 325-358 °C |
| Temperature range | 325-358 °C |
| Type | Soldering tip |
| Tip shape | Micro fine |
| Tip alignment | Bevelled, 45° |
| Tip length | 16 mm (0.63 in) |
| Tip width | 0.7 mm (0.03 in) |
| Suitable hand piece | SHP-T |
| Suitable systems | TMT-5000S-1, TMT-5000S-2 |
| Order unit | Piece |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm (4.6 in x 1.3 in x 0.5 in) |
| Weight | 0.1 kg |
| Design | RoHS compliant, lead-free capable |
Applications
Soldering and correcting 0201 and 0402 packages, fine trace repair, microscope work on measuring and medical electronics assemblies.
Compatibility and scope of delivery
Suitable for the SHP-T hand piece on TMT-5000S-1 and TMT-5000S-2. One tip cartridge is supplied, hand piece and power unit are not part of the delivery.
