ESD extraction arm with fitted nozzle 50 mm for WLA 250 - Donaldson Bofa A1020331

An extraction arm is only worth its price if it captures fume at the joint instead of drawing it past the operator's face. The A1020331 is articulated, holds its position without readjustment and comes with the nozzle already fitted. Its 50 mm connection diameter mates directly with the Weidinger WLA 250.

Benefits

• ESD-safe design, no charging risk above sensitive assemblies
• Nozzle already fitted, ready for use without additional parts
• 50 mm connection diameter for direct coupling to the WLA 250
• Articulated arm stays in the set position and leaves both hands free
• Capture directly at the solder joint instead of dilution into the room

Technical data

Applications

The arm is used at hand soldering positions, repair and rework benches in electronics manufacturing and at bonding or dispensing stations that generate aerosols. The ESD-safe design is a requirement wherever electrostatic discharge sensitive devices are handled.

Compatibility and scope of delivery

Intended for the Weidinger WLA 250 extraction unit. Supplied as one A1020331 extraction arm with the nozzle fitted. Filters and the extraction unit are ordered separately.

The ESD-safe design supports operation in EPA workplaces according to IEC 61340-5-1.
