Brushless ESD electric screwdriver, lever start, 1.96-4.90 Nm, 120 W - Kilews SKD-BN850L-ESD

Electronics assembly needs every screw pulled to the same torque across thousands of cycles. The SKD-BN850L-ESD covers 1.96 to 4.90 Nm with stepless adjustment and shuts off through its clutch the moment the preset value is reached. The 120 W brushless motor does this without carbon brushes, which means no brush dust inside the housing and no scheduled brush change.

What sets this screwdriver apart

• Torque range 1.96 to 4.90 Nm, set steplessly, so one tool covers several joints on the same assembly.
• Brushless motor rated 120 W at 40 V, maintenance-free and quiet in continuous use.
• ESD compliant version according to the manufacturer, suited to workstations handling static-sensitive components.
• Lever start releases the cycle through the switch lever and lets the operator seat the bit without preload on the screw.
• No-load speed 700 to 1000 rpm, switched between LO and HI on the power supply.
• Output 1/4 inch hex, matching standard bits and the angle heads of the series.

Technical data

Applications

PCB and module assembly, enclosure assembly in equipment manufacturing, assembly lines in mechanical engineering and rework stations with changing fastening tasks. The tool is built for continuous duty at a fixed workstation rather than for mobile use.

Compatibility and scope of delivery

The screwdriver runs on the SKP-40B-HLN power supply and on the SKP-BC40HLN V4.0 and V4.1 controllers. The KL-1B angle head with 1/4 inch hex drive is specified for the SKD-BN8xx series. According to the datasheet the delivery includes torque sleeve, connection cable and power supply.
