Digital 2-channel supply unit WT 2M, 150 W, 50-450°C - Weller WT 2M
With 150 W the WT 2M runs two soldering tools at once through intelligent power sharing. It is backwards compatible with Weller micro tools and many passive-tip tools, temperature range 50-450°C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The WT 2M is a multifunctional digital 2-channel supply unit rated at 150 W. Intelligent power sharing lets you run two soldering tools in parallel; the unit is backwards compatible with Weller micro tools and many passive-tip tools.
Benefits
- Run 2 soldering tools in parallel thanks to intelligent power sharing
- Works with cartridge-tip (RT) active tools and many passive-tip tools
- Intuitive operating concept with backlit LCD
- Stackable design for a small footprint
- Automatic switch-off via the usage sensor in the tool
- Housing cover usable as an extra rest
- Adjustable OFF time, process window, interlock, offset
Applications
- Workstations using two soldering tools
- Electronics manufacturing and rework with micro and standard tools
Compatibility
- Compatible soldering iron: WMRP, WMRP MS
- Active tools with RT cartridge tips and many passive-tip tools
CE and RoHS compliant, ESD-safe. Made in Germany.
Technical data
| Model | WT 2M |
|---|---|
| Manufacturer item no. | T0053443399 |
| Power | 150 W |
| Voltage | 230 V |
| Fuse | 0.8 A |
| Temperature range | 50-450 °C |
| Temperature stability | ±2 °C |
| Number of channels | 2 |
| Dimensions (LxWxH) | 149 x 138 x 101 mm |
| Overcurrent release | T40/B |
| Display | backlit LCD |
| Weight | 1.9 kg |
| Manufacturer | Weller |
| Manufacturer Nr. | T0053443399 |
| HS-Code | 85151100 |
| GPSR manufacturer information | WELLER Tools GmbH Carl-Benz-Strasse 2 DE-74354 Besigheim www.weller.eu |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Mexico |
| ESD version | ESD (antistatic) |
Downloads
Datasheet
Catalogue
