ESD divider insert conductive 549x139 mm for CSC containers (20-CSC-L20) - Hans Kolb 12000046
Conductive solid-board divider insert for CSC containers, 549x139 mm. Splits the container into up to 400 ESD-safe compartments on a 20 mm grid and keeps components in place per IEC 61340-5-1.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The 20-CSC-L20 divider insert organises a CSC container into separate, clearly defined compartments and holds ESD-sensitive components securely in place during storage and in-house transport. The solid board is conductively coated on both sides and dissipates static charges in a controlled way.
Benefits
- Up to 400 compartments per container for high packing density
- 20 mm grid with 24 slots for flexible layouts
- Conductive coating on both sides, typical bleeder resistance 10⁷ to 10⁹ Ohm
- Exact fit inside the CSC container, 549x139 mm footprint
Technical data
| Weight | 0.077 kg |
|---|---|
| Manufacturer | Hans Kolb |
| Manufacturer Nr. | 12000046 |
| HS-Code | 48192000 |
| GPSR manufacturer information | HANS KOLB Dr.-Lauter-Strasse 2 DE-87700 Memmingen www.kolb-wellpappe.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Colour | Black |
| ESD version | ESD (antistatic) |
| Certification | IEC 61340-5-1 |
- Model: 20-CSC-L20
- Dimensions (LxW): 549 x 139 mm
- Min. compartment size (LxWxH): 20x20x139 mm
- Max. number of compartments: 400
- Max. number of bars: 15
- Grid: 20 mm
- Number of slots: 24
- Material: conductive solid board, black
- ESD-safe to IEC 61340-5-1
- Manufacturer item no.: 12000046
Suitable for CSC containers used to store and transport printed circuit boards and electronic assemblies.
