ESD separators Carbostat LP, 3-layer, 160 µm, 350 x 250 mm, black, pack of 500 - Warmbier 3252.350.250

When boards and assemblies are stacked inside a storage container, a separator protects the surfaces and keeps the charge situation in the stack under control. The Carbostat LP separator is a three-layer, permanently volume-conductive film of 160 µm with a typical resistance to ground of 10^4 - 10^5 Ohm.

Benefits

• Permanently volume-conductive, the conductivity sits in the film itself rather than in a surface coating.
• Three-layer structure, outer and inner layers smooth.
• 160 µm film thickness, stable enough for repeated insertion and removal.
• Weldable and recyclable.
• Supplied without imprint, so it can carry your own marking.
• Cut to 350 x 250 mm, matched to 400 x 300 mm storage containers. Pack of 500 pieces.

Application

Inside an EPA the separators go between stacked boards, underneath assemblies in the storage container and on the container floor as a lining. As the film is weldable, it can also be processed into bags and lids.
