Lineman's pliers with fish tape puller and mandrel crimping point, 240 mm - Knipex 09 11 240

Pulling conductors into conduit and crimping ferrules normally means changing tools. The lineman's pliers 09 11 240 saves that step with a fish tape puller in the joint gap and a universal mandrel crimping point below the joint, and it still cuts hard wire up to Ø 3.0 mm.

Benefits

• Fish tape puller in the joint gap for a safe grip on the pulling tape, with no extra tool.
• Universal mandrel crimping point below the joint for connectors straight from the pliers.
• Optimised transmission ratio requires about 50 % less effort than conventional combination pliers.
• Cross-hatched gripping zone in the jaws for firm gripping and pulling, additional gripping zone below the joint for powerful leverage and pressing.
• Cutting edges for soft and hard wire, induction-hardened to about 62 HRC, medium-hard wire up to Ø 4.6 mm.
• Solid construction for the heaviest strain, ergonomic handle shape with slip-resistant plastic, 435 g at 240 mm length.

Areas of use

Electrical installation and utility line work, first fix and retrofitting, wherever conductors are pulled into empty conduit and connectors are crimped afterwards. Equally at home in plant construction and maintenance.

Standards and conformity

The pliers comply with DIN ISO 5746 and ASME B107.20. According to the manufacturer they contain no substances of very high concern under REACH, the RoHS directive does not apply.
