Knipex
Circlip pliers for large external circlips on shafts, Ø 252 - 400 mm, 570 mm - Knipex 46 10 A6
Item WL61529
€117.45
Images are examples, some edited with AI. The technical data are authoritative. AI notice
Circlip pliers for large external circlips on shafts, Ø 122 - 300 mm, 560 mm - Knipex 46 10 A5
Circlip pliers for large external circlips on shafts from Ø 122 - 300 mm with releasable locking device and replaceable tips of 3.5 mm. Black powder-coated, 560 mm long, 1,773 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Large external circlips on shafts from Ø 122 - 300 mm need a long spreading travel and a lot of force. These 560 mm pliers deliver both and hold the ring open with the releasable locking device, so one hand stays free for fitting.
Benefits
- Releasable locking device keeps rings up to 300 mm open without further hand pressure.
- Replaceable tips of 3.5 mm can be exchanged after wear instead of replacing the whole pliers.
- Lever travel over a length of 560 mm provides the spreading force even for strong rings.
- Black powder coating protects the large legs against corrosion.
- Dimensions 560 x 102 x 16 mm, so the space needed in the workshop can be planned in advance.
Applications
Large gearboxes, roller bearings, construction and agricultural machinery and industrial drives where circlips on shafts of this size have to be changed.
Standards and conformity
The pliers contain substances of very high concern under REACH. The RoHS directive is not applicable to this hand tool.
Technical data
| EAN | 4003773024996 |
|---|---|
| Pliers | black powder-coated |
| Capacity for shaft diameter | Ø 122 - 300 mm |
| Tips (diameter) | 3.5 mm |
| Weight | 1,773 g |
| Dimensions | 560 x 102 x 16 mm |
| REACH conformity | contains SVHC |
| RoHS conformity | not applicable |
| Manufacturer | Knipex |
| Manufacturer Nr. | 46 10 A5 |
| HS-Code | 82032000 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Height | 16 mm |
| Width | 102 mm |
| Colour | Black |
| Farbe | schwarz |
| Overall length [mm] | 560 |
Downloads
Videos
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
