Screwdriver for cross recessed screws Phillips PH1, VDE insulated, 187 mm - Knipex 98 24 01

When working on live installations, the insulation of the tool decides how safe the job is. The 98 24 01 screwdriver is VDE tested to DIN EN 60900 and IEC 60900 and drives Phillips cross recessed screws in size PH1 with a blade of 80 mm, of which only the front 15 mm stay uninsulated.

Benefits

• Insulating multi-component handle and insulated blade, VDE tested to DIN EN 60900 and IEC 60900.
• Ergonomically optimised dual component handle for fatigue reduced work and optimum transmission of force, handle length 107 mm.
• Handle design prevents rolling, the tool stays put on sloping surfaces and inside the cabinet.
• Black oxide finished tip in size PH1 for a secure seat in the screw head.
• Only the front 15 mm of the blade are uninsulated, overall length 187 mm at 58 g.

Areas of use

Electrical installation, control cabinet and plant construction, maintenance and field service on machinery. Wherever screws are driven on or next to live parts, an insulated tool according to IEC 60900 is mandatory.

Standards and conformity

The tool is built and tested to DIN EN 60900 and IEC 60900. These standards cover hand tools for live working up to 1000 V AC. According to the manufacturer the screwdriver contains no substances of very high concern under REACH and the RoHS directive does not apply.
