Large steel base plate 400x300x29.5 mm with anti-shock feet - Leica 10446437
Steel base plate with a 400 x 300 mm bearing surface and 29.5 mm thickness for swivel arm systems and heavy equipment with accessories. The high mass keeps the optics steady and the anti-shock feet decouple the plate from the bench. The image stays put even with the arm fully extended.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A swivel arm stand is only as steady as its base plate. This steel plate with a 400 x 300 mm bearing surface and 29.5 mm thickness carries the weight of large swivel arm systems including accessories and damps shocks from the surroundings through anti-shock feet.
Benefits in use
- Footprint of 400 x 300 mm, enough bearing surface for large swivel arm systems with illumination and camera.
- Plate thickness 29.5 mm in steel, the high mass keeps the optics steady under vibration.
- Anti-shock feet decouple the plate from the workbench and damp shocks from the surroundings.
- Rated for heavy equipment with accessories, the setup stays stable even with the arm fully extended.
Applications
Swivel arm workstations in assembly inspection, measuring and documentation stations with a camera, and rework benches where tools rest next to the sample.
Compatibility and scope of delivery
Intended for the Leica swivel arm system and for heavy setups with accessories. Supplied as the base plate with anti-shock feet. Vertical column, horizontal arm, focusing drive and microscope body are not included.
Technical data
| Property | Value |
|---|---|
| Brand | Leica |
| Model number | 10446437 |
| Type | Base plate, large |
| Material | Steel |
| Length | 400 mm |
| Width | 300 mm |
| Height | 29.5 mm |
| Feet | Anti-shock |
| Intended for | Swivel arm system and heavy equipment with accessories |
| Sales unit | 1 piece |
| Content unit | 1 piece |
| Battery included | no |
| Weight | 0.19 kg |
| Manufacturer | Leica |
| Manufacturer Nr. | 10446437 |
| HS-Code | 90119000 |
| GPSR manufacturer information | LEICA Mikrosysteme, Ernst-Leitz-Straße 17-37, DE-35578 Wetzlar, www.leica-microsystems.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Switzerland |
